- Porsche 924S 2.5L 1986-87
- Porsche 924S 2.5L 1988
- Porsche 944 2.5L 8V 1982-87
- Porsche 944 2.7L 8V 1988-89
- Porsche 944S 2.5L 16V 1987-88
- Porsche 944S2 3.0L 16V 1989-91
- Porsche 944 Turbo 2.5L 8V 1985-88
- Porsche 944 Turbo 2.5L 8V 1989-91
- Porsche 944 Turbo S 2.5L 8V 1988
- Porsche 968 3.0L 1992-94
- Porsche 968 Sport 3.0L 1994-95
- Porsche 968 CS 3.0L 1993-95
- Porsche 968 Turbo S 3.0L 1993-94
Fits:
Porsche 944 1982-1985 Chassis F 94DN4 01735>>
Porsche 944 1985-89
Porsche 924S 1986-1988
Porsche 968 1992-1995
Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.
94462402105
The product you are viewing cross references to these numbers
- Porsche 991.2 Carrera 2 3.0L (370 Bhp) 2016-19
- Porsche 991.2 Carrera 2S / GTS 3.0L (420/450 Bhp) 2016-19
- Porsche 991.2 Carrera 4 3.0L (370 Bhp) 2016-19
- Porsche 991.2 Carrera 4S / GTS 3.0L (420/450 Bhp) 2016-19
- Porsche 991.2 Cabriolet 2 3.0L (370 Bhp) 2016-19
- Porsche 991.2 Cabriolet 2S / GTS 3.0L (420/450 Bhp) 2016-19
- Porsche 991.2 Cabriolet 4 3.0L (370 Bhp) 2016-19
- Porsche 991.2 Cabriolet 4S / GTS 3.0L (420/450 Bhp) 2016-19
- Porsche 991.2 Targa 4 3.0L (370 Bhp) 2016-19
- Porsche 991.2 Targa 4S / GTS 3.0L (420/450 Bhp) 2016-19
- Porsche 958 Cayenne V6 3.6L Petrol (300Hp) 2010-17
- Porsche 958 Cayenne V6 3.0L Diesel (245Hp) 2010-17
- Porsche 958 Cayenne S V6 3.0L Hybrid (380Hp) 2010-17
- Porsche 958 Cayenne S V8 4.8L Petrol (400Hp) 2010-17
- Porsche 958 Cayenne S V8 4.2L Diesel (382Hp) 2010-17
- Porsche 958 Cayenne GTS V8 4.8L Petrol (400Hp) 2010-17
- Porsche 958 Cayenne Turbo V8 4.8L Petrol (500Hp) 2010-17
- Porsche 958 Cayenne Turbo S V8 4.8L Petrol (550Hp) 2010-17
- Porsche 95B.1 Macan Petrol 2.0L (237Bhp) 2014-18
- Porsche 95B.1 Macan S Petrol 3.0L V6 (340Bhp) 2014-18
- Porsche 95B.1 Macan S Diesel 3.0L V6 (258Bhp) 2014-18
- Porsche 95B.1 Macan GTS Petrol 3.0L V6 (360Bhp) 2014-18
- Porsche 95B.1 Macan Turbo 3.6L V6 (400Bhp) 2014-18
Porsche air guide servomotor for front cooling-air adjustment on selected 991.2 911, 95B.1 Macan and 958 Cayenne applications.
Fits:
- Porsche 991.2 Carrera 2 3.0L (370 Bhp) 2016-19
- Porsche 991.2 Carrera 2S / GTS 3.0L (420/450 Bhp) 2016-19
- Porsche 991.2 Carrera 4 3.0L (370 Bhp) 2016-19
- Porsche 991.2 Carrera 4S / GTS 3.0L (420/450 Bhp) 2016-19
- Porsche 991.2 Cabriolet 2 3.0L (370 Bhp) 2016-19
- Porsche 991.2 Cabriolet 2S / GTS 3.0L (420/450 Bhp) 2016-19
- Porsche 991.2 Cabriolet 4 3.0L (370 Bhp) 2016-19
- Porsche 991.2 Cabriolet 4S / GTS 3.0L (420/450 Bhp) 2016-19
- Porsche 991.2 Targa 4 3.0L (370 Bhp) 2016-19
- Porsche 991.2 Targa 4S / GTS 3.0L (420/450 Bhp) 2016-19
- Porsche 958 Cayenne V6 3.6L Petrol (300Hp) 2010-17
- Porsche 958 Cayenne V6 3.0L Diesel (245Hp) 2010-17
- Porsche 958 Cayenne S V6 3.0L Hybrid (380Hp) 2010-17
- Porsche 958 Cayenne S V8 4.8L Petrol (400Hp) 2010-17
- Porsche 958 Cayenne S V8 4.2L Diesel (382Hp) 2010-17
- Porsche 958 Cayenne GTS V8 4.8L Petrol (400Hp) 2010-17
- Porsche 958 Cayenne Turbo V8 4.8L Petrol (500Hp) 2010-17
- Porsche 958 Cayenne Turbo S V8 4.8L Petrol (550Hp) 2010-17
- Porsche 95B.1 Macan Petrol 2.0L (237Bhp) 2014-18
- Porsche 95B.1 Macan S Petrol 3.0L V6 (340Bhp) 2014-18
- Porsche 95B.1 Macan S Diesel 3.0L V6 (258Bhp) 2014-18
- Porsche 95B.1 Macan GTS Petrol 3.0L V6 (360Bhp) 2014-18
- Porsche 95B.1 Macan Turbo 3.6L V6 (400Bhp) 2014-18
Diagram Ref No 4
Confirm the vehicle's model, production year, engine and applicable assembly before ordering, particularly where the diagram coverage is narrower than the supplied vehicle applications.
What This Product Does
The electrically operated servomotor adjusts the position of connected air-guide flaps or vanes in the relevant front assembly. It supplies the movement needed for the vehicle's cooling-air control mechanism rather than serving as a fixed duct or complete bumper component.
Functions
- Drives the linked cooling-air adjustment mechanism.
- Positions connected flaps or vanes under electrical control.
- Forms part of the applicable front air-guide assembly.
Technical Details
- Brand: Porsche; genuine adjustment servomotor.
- Part identifier: 95B965501AA.
- Installation position: Front, as recorded for the 991.2 and Cayenne diagrams.
- 991.2 diagram entry: Servomotor Disc pack; assembly quantity two.
- 95B.1 Macan diagram entry: Servomotor Disc pack; assembly quantity one.
- 958 Cayenne diagram entry: Seromotor; assembly quantity one. Diagram quantities describe vehicle assembly usage, not pack contents.
Symptoms of Fault
- No response from the flaps during an actuation check.
- Adjustment that stops part-way or works inconsistently.
- Diagnostic fault information identifying an actuator-related issue.
- Physical deterioration affecting the motor housing, connection or attached mechanism.
Why Replacement Matters
When the servomotor fails, the attached vanes may remain in an incorrect position instead of responding to adjustment commands. Renewing a confirmed faulty motor addresses the missing electrical actuation, but will not correct a jammed linkage or damaged flap assembly.
Inspect the wiring connection, mechanical linkage and surrounding air-guide components before replacing the motor. Check for obstructions and use diagnostic testing to distinguish an actuator defect from an electrical supply or mechanical problem.
Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.
95B965501AA
The product you are viewing cross references to these numbers
