engine lubrication oil tank for 997.1 TURBO/GT2 M97.70 2007-09 and 997.1 GT2 RS M97.70 2011 - PORSCHE

Klik op de afbeeldingsnummers om productinformatie te bekijken

Diagram 104-05 Porsche Cayenne S V8 4.8L Benzine 400 pk MotorSKU: 99720707072, oil tankSKU: 99320722600, gasketSKU: 99620715073, intermediate pieceSKU: 90037700901, hexagon nut m 5SKU: 99620721270, flangeSKU: 99970734341, o-ring 25,07 x 2,62SKU: 99720701670, filler tubeSKU: 99970748140, o-ring 24 x 3,0SKU: 99610703552, lidSKU: 99610733600, gasketSKU: 99720721673, support for filler tubeSKU: 99907318901, round head screw m 6 x 12SKU: 9A700812500, torx screw m 6 x 16SKU: PAF008126, torx screw m 6 x 20SKU: PAF008126, torx screw m 6 x 20SKU: 99660614000, oil-level senderSKU: 99970219340, rubber sleeve 17,0 x 24,0 x 1,8SKU: 99970219340, rubber sleeve 17,0 x 24,0 x 1,8SKU: 99970219340, rubber sleeve 17,0 x 24,0 x 1,8SKU: 99920903701, spacer sleeve 8,4 x 1,8SKU: 99920903701, spacer sleeve 8,4 x 1,8SKU: 90038511601, torx screw m 8 x 30SKU: 90038511601, torx screw m 8 x 30SKU: 90038511601, torx screw m 8 x 30SKU: 99720741771, supportSKU: 90012301020, sealing ringSKU: 90006501800, screw plugSKU: 90038504201, torx screw m 8 x 35SKU: PAF001704, torx screw m 8 x 20SKU: 99970731641, o-ring 21,89 x 2,62SKU: 99620701274, intake connectionSKU: 99970736441, sealing ring 30 x 2,5SKU: 99720703771, vent lineSKU: 99720713971, hose tank ventilationSKU: 99951265209, hose clamp 19 x 12SKU: 99951265109, hose clamp 15 x 12SKU: 99720714371, hoseSKU: 99951225202, hose clamp 23 - 35/9SKU: 99620720773, spacerSKU: 99620720673, spacerSKU: 90024906101, countersunk-head screw m 12 x 40SKU: 90024906101, countersunk-head screw m 12 x 40104-05
Nr. (Nummer)Onderdeelnr.BeschrOpmerkingModel
199720707072oil tank
299320722600gasket
399620715073intermediate piece
490037700901hexagon nut M 5
599620721270flange
699970734341o-ring 25,07 X 2,62
799720701670filler tube
899970748140o-ring 24 X 3,0
999610703552lid
1099610733600gasket
1199720721673support for filler tube
1299907318901round head screw M 6 X 12
139A700812500torx screw M 6 x 16
14PAF008126torx screw M 6 X 20
1599660614000oil-level sender
1699970219340rubber sleeve 17,0 X 24,0 X 1,8
1799920903701spacer sleeve 8,4 X 1,8
1890038511601torx screw M 8 X 30
1999720741771support
2090012301020sealing ring
2190006501800screw plug
2290038504201torx screw M 8 X 35
23PAF001704torx screw M 8 X 20
2599970731641o-ring 21,89 X 2,62
2699620701274intake connection
2799970736441sealing ring 30 X 2,5
2899720703771vent line
2999720713971hose tank ventilation
3099951265209hose clamp 19 X 12
3199951265109hose clamp 15 X 12
3299720714371hose
3399951225202hose clamp 23 - 35/9
3499620720773spacer
3599620720673spacer
3690024906101countersunk-head screw M 12 X 40
3799720723772moulded hose
3899951255101hose clamp
